Bharat Mineral Processing Equipment’s is one of India’s most reliable manufacturers and suppliers of double roll crushers, recognized for high-quality products at competitive prices. We invite you to contact us with confidence for customized double roll crushers direct from our factory.

The laboratory double roll crusher (also known as a lab roller crusher) operates using two counter-rotating rollers. Material enters tangentially between the rollers, where the gap progressively narrows. As the rollers rotate, they exert a continuous biting and squeezing force that crushes the material into fine particles before discharging it.

The roll gap can be adjusted from 0 mm to 20 mm to achieve your target particle size.

Basic Structure

The unit mainly consists of:

• Fixed and movable rollers
• Transmission shafts
• Machine body and underframe
• Protective covers and long gear covers

Driven by an electric motor via a V-belt, the main shaft and gear system rotate the rollers along a calibrated trajectory to efficiently crush materials within the crushing chamber.

This series is specially designed for both continuous and batch crushing of various ores, coal, chemical raw materials, and similar samples. Recent updates to this model have significantly boosted production efficiency, making it an ideal choice for modern laboratory environments.

• Target Industries: Coal, power generation, chemical processing, building materials, scientific research, and quality control labs.

• Crushing Stage: Medium to fine crushing via double-roll extrusion.

• Type: Best suited for brittle materials that produce regular, flake-like crushed particles.

• Compressive Strength: Maximum 60 MPa.

• Hardness: Grade 3 or below.

• Moisture Content: Must be under 6% to prevent material from sticking to the rollers.

• Simple & Flexible: Easy-to-adjust discharge gap for precise particle size control.

• Dust-Controlled: Integrated dust-proof enclosure prevents airborne contamination and keeps the workspace clean.

• Durable Build: Constructed from high-grade materials for long-term reliability and heavy lab use.
